Generator Pemulihan Panas Tekanan Tinggi Beredar Secara Alami Untuk Industri
Detail Produk
| Tipe: | Sirkulasi Alami | Pemakaian: | Industri dan pembangkit listrik |
|---|---|---|---|
| Gaya: | Horisontal vertikal | Tekanan: | Tekanan Rendah / Menengah / Tinggi |
| Kondisi: | Baru | Bobot: | Disesuaikan |
| Menyoroti |
boiler pemulihan panas limbah,boiler industri dan generator uap pemulihan panas |
||
Deskripsi Produk
Generator Pemulihan Panas Tekanan Tinggi Beredar Secara Alami Untuk Industri
♢ Apa itu HRSG?
|
♢ Apa prinsip kerja HRSG?
|
♢ Apa keuntungan dari HRSG?
| Fitur Kiln (AQC) HRSG | Fitur Kiln (SP) HRSG |
| 1. struktur perakitan modular, ekspansi penyegelan yang andal | 1. Heating surface tube dan header dengan struktur koneksi privildged, mengurangi guncangan mekanis dan getaran |
| 2. Mengadopsi memakai tabung sirip, jaminan hidup bagian tekanan boiler | 2. Dengan mode pembersihan getaran mekanis, mode pembersihan terus menerus berdampak kecil pada operasi sistem |
| 3. Teknologi flash yang unik, suhu outlet boiler berkurang hingga di bawah 90ºC | 3. Atur mesin abu-abu scraper tertutup, sangat mengurangi ekor debu. |
♢ Apa saja parameter HRSG?
| Kapasitas lini produksi semen t / d | 1000 | 2500 | 5.000 | 10000 | |
| Aliran masuk boiler Nm3 / jam | Kiln (depan) | 60.000 | 88000 | 243000 | 472000 |
| Kiln (ekor) | 76000 | 170000 | 328000 | 612000 | |
| Suhu gas masuk boiler ℃ | Kiln (depan) | 370 | 360 | 380 | 390 |
| Kiln (ekor) | 360 | 320 ~ 360 | 330 | 330 | |
| Nilai penguapan t / jam | Kiln (depan) | 5.8 | 7.25 | 24 | 50 |
| Kiln (ekor) | 7.5 | 10 ~ 15.8 | 20 ~ 24.6 | 35.5 | |
| Nilai tekanan uap Mpa | Kiln (depan) | 1.25 | 1.25 | 1.25 | 1.25 |
| Kiln (ekor) | 1.25 | 1.25 | 1.25 | 1.25 | |
| Suhu uap terukur ℃ | Kiln (depan) | 340 | 330 | 350 | 360 |
| Kiln (ekor) | 340 | 300 ~ 340 | 310 | 310 | |
| Struktur boiler | Kiln (depan) | Vertikal | Vertikal | Vertikal | Vertikal |
| Kiln (ekor) | Vertikal | Vertikal dan Horizontal | Vertikal dan Horizontal | Vertikal | |
♢ Mengapa Anda memilih HDB?
|
|
|
Hua Dong memegang lisensi manufaktur untuk boiler Grade A dan bejana tekan Grade A1 & A2 yang dikeluarkan oleh Administrasi Umum China untuk Pengawasan Kualitas, Inspeksi dan Karantina;juga memegang perangko "S" dan "U" "NB" yang dikeluarkan oleh American Society of Mechanical Engineers;Sementara itu, Perusahaan ini telah lulus sertifikasi Sistem Manajemen Mutu ISO9001, SO3834, EN12952. |
