Vertical Gas Oil Fired Thermic Fluid Boiler Efisiensi Tinggi, Emisi Polusi Rendah
Detail Produk
| Bahan bakar: | Gas, Minyak Terbakar | Tekanan: | Tekanan rendah |
|---|---|---|---|
| Place Style: | Vertikal | Media: | Bahan Perpindahan Panas Organik |
| Pemakaian: | Industri | Spesifikasi: | Disesuaikan |
| Pengobatan permukaan: | Dilukis | Pelabuhan: | Shanghai |
| Menyoroti |
boiler fluida termal,boiler minyak pemanas |
||
Deskripsi Produk
Chain Grate Vertical Gas Oil dipecat Thermal Fluid Heater Emisi polusi rendah
Deskripsi
Asap api dan suhu tinggi yang dihasilkan oleh pembakaran bahan bakar yang lengkap (minyak diesel ringan, minyak berat, minyak sisa, gas alam, gas minyak cair, gas kota, dll.) Pertukaran panas dengan media perpindahan panas organik di dalam pipa melalui transfer radiasi dan transfer konveksi , pada saat yang sama, media perpindahan panas organik bersirkulasi dalam sistem yang didorong oleh pompa.Dan kemudian peralatan menggunakan-panas mengambil panas dari media, yang kembali ke boiler setelah pertukaran panas.Jadi ini adalah sistem sirkulasi panas organik.
Parameter Teknis
|
Model YYL (W) |
350 Y (Q) |
600 Y (Q) |
900 Y (Q) |
1200 Y (Q) |
1500 Y (Q) |
1800 Y (Q) |
23.00 Y (Q) |
2900 Y (Q) |
3500 Y (Q) |
||
| Nilai daya (kw) | 350 | 600 | 900 | 1200 | 1500 | 1800 | 23.00 | 2900 | 3500 | ||
| Pasokan panas × 104(kCal / jam) | 30 | 50 | 75 | 100 | 160 | 150 | 200 | 250 | 300 | ||
| Efisiensi termal (%) | ≥88 | ≥88 | ≥88 | ≥88 | ≥90 | ≥90 | ≥90 | ≥90 | ≥90 | ||
| Tekanan desain (MPa) | 1.1 | 1.1 | 1.1 | 1.1 | 1.1 | 1.1 | 1.1 | 1.1 | 1.1 | ||
| Suhu kerja maksimum (℃) | 320 | 320 | 320 | 320 | 320 | 320 | 320 | 320 | 320 | ||
| Tingkat sirkulasi sedang (m3/ h) | 40 | 58 | 100 | 100 | 100 | 160 | 160 | 200 | 200 | ||
| Kapasitas medium tungku (m3) | 0.4 | 0.6 | 0.6 | 0.8 | 1.2 | 2.1 | 2.6 | 3.5 | 7.8 | ||
| Diameter yang kompeten (DN) | 100 | 100 | 125 | 125 | 125 | 150 | 150 | 200 | 200 | ||
| Kapasitas (kw) | 14.5 | 18 | 31 | 37.5 | 49.5 | 57.5 | 61.5 | 75 | 75 | ||
| Bahan bakar yang dapat digunakan | Minyak gas | ||||||||||
| Konsumsi bahan bakar Kg / jam (minyak) | 34 | 56 | 84 | 111 | 141 | 163 | 217 | 273 | 326 | ||
|
Ukuran (￠ · H) m |
Tungku minyak vertikal | 1,3 × 2,5 | 2 × 3.5 | 2.1 × 3.5 | 2.2 × 3.5 | 2,2 × 4 | 2.2 × 4.4 | 2.7 × 5.1 | 2,8 × 6,5 | 3,2 × 6,7 | |
|
Sirkulasi pompa |
Model WRY | 80-50-180 | 100-65-190 | 100-65-230 | 100-65-240 | 100-65-257 | 125-80-250 | 125-80-250 | 125-100-250 | 125-100-250 | |
| Arus (m3/ h) | 40 | 60 | 100 | 100 | 100 | 160 | 160 | 200 | 200 | ||
| Angkat (m) | 40 | 38 | 55 | 70 | 80 | 60 | 60 | 60 | 60 | ||
| Daya (kw) | 7.5 | 11 | 22 | 30 | 37 | 45 | 45 | 55 | 55 | ||
|
Model YYL (W) |
4700 Y (Q) |
5900 Y (Q) |
7000 Y (Q) |
8200 Y (Q) |
9400 Y (Q) |
10500 Y (Q) |
12000 Y (Q) |
14000 Y (Q) |
16300 Y (Q) |
||
| Nilai daya (kw) | 4700 | 5900 | 7000 | 8200 | 9400 | 10500 | 12000 | 14000 | 16300 | ||
| Pasokan panas × 104 (kCal / jam) | 400 | 500 | 600 | 700 | 800 | 900 | 1000 | 1200 | 1400 | ||
| Efisiensi termal (%) | ≥90 | ≥90 | ≥90 | ≥90 | ≥90 | ≥90 | ≥90 | ≥90 | ≥90 | ||
| Tekanan desain (MPa) | 1.1 | 1.1 | 1.1 | 1.1 | 1.1 | 1.1 | 1.1 | 1.1 | 1.1 | ||
| Suhu kerja maksimum (℃) | 320 | 320 | 320 | 320 | 320 | 320 | 320 | 320 | 320 | ||
| Tingkat sirkulasi sedang (m3 / jam) | 260 | 300 | 340 | 400 | 520 | 600 | 600 | 680 | 800 | ||
| Kapasitas medium tungku (m3) | 8.4 | 8.8 | 10.5 | 11.2 | 11.5 | 13 | 15 | 18 | 23 | ||
| Diameter yang kompeten (DN) | 200 | 250 | 250 | 250 | 300 | 300 | 300 | 350 | 350 | ||
| Kapasitas (kw) | 98.5 | 121.5 | 148.5 | 155 | 195 | 235 | 235 | 295 | 341 | ||
| Bahan bakar yang dapat digunakan | Minyak gas | ||||||||||
| Konsumsi bahan bakar Kg / jam (minyak) | 435 | 545 | 660 | 760 | 875 | 980 | 1140 | 1360 | 1600 | ||
|
Ukuran (￠ · H) m |
Tungku minyak vertikal | 3,2 × 7 | 3,3 × 7,5 | 3,5 × 8,2 | 3.62 × 9.2 | 3,7 × 9,6 | 3.65 × 11 | 3.65 × 11 |
3,98 × 11.8 |
4,06 × 12.8 |
|
|
Sirkulasi pompa |
Model WRY | 125-100-257 |
125- 100-260 |
150-125-270 | 125-100-250 | 125-100-257 | 125-100-260 | 150-100-260 | 150-125-270A | 150-125-280 | |
| Arus (m3 / jam) | 260 | 300 | 340 | 200 × 2 | 260 × 2 | 300 × 2 | 300 × 2 | 340 × 2 | 400 × 2 | ||
| Angkat (m) | 70 | 70 | 76 | 60 | 70 | 70 | 70 | 76 | 78 | ||
| Daya (kw) | 75 | 90 | 110 | 55 × 2 | 75 × 2 | 90 × 2 | 90 × 2 | 110 × 2 | 132 × 2 | ||
Pengenalan Perusahaan
Didirikan pada tahun 1985, Zhangjiagang Hua Dong Boiler Co., Ltd. (diperdagangkan sebagai HD Boiler), memproduksi pembangkit listrik;industri;buang panas;pembakaran sampah;biomassa;pembawa panas organik dan ketel uap listrik.Ditambah dengan rangkaian luas permukaan pemanas, HD Boiler menghadirkan layanan unik ke pasar termasuk desain boiler, fabrikasi, pemasangan, pemeliharaan, dan penggantian suku cadang tekanan boiler.
1. Fabrikasi seluas 200.000 meter persegi
2. 150 Insinyur
3. 600 tukang las berkode
4. 60 Pengawas Berlisensi (instruktur NDT Level-III)
5. Lisensi Kelas-A untuk Desain dan Pembuatan Boiler
6. Sistem Mutu ISO 9001: 2008
7. Sertifikat ASME untuk Power Boiler
8. Otorisasi stempel ASME 'S', 'U' dan NB
